Brand: MITSUBISHI/Japan Mitsubishi
Origin: Category Imported
A1SY28A Mitsubishi Ans series output module performance specifications
[Output points] 8 points
[Rated switching voltage and frequency] AC100/240V, 50/60Hz±3Hz
[Maximum load voltage] AC264V
[Maximum load current] 1A/point, 8A/common (AC132V, 46℃), 8A/common (AC264V, 40℃), 4A/common (AC132V, 55℃), 2A/common (AC264V, 55 ℃)
[Minimum load voltage and current] AC24V 100mA, AC100V 55mA, AC240V 55mA
[Maximum inrush current] 25A 10ms or less, 10A 100ms or less
[Leakage current when OFF] 3mA or less (at AC240V 60Hz), 1.5mA or less (at AC120V 60Hz)
[Maximum voltage when ON] AC1.5V or less (0.2~1A), AC1.8V or less (0.1~0.2mA), AC3V or less (55~100mA)
[Input response time] OFF-->ON 1ms or less; ON-->OFF 1ms+0.5 cycle or less
[Surge limiter] CR absorber (0.01μF+47Ω)
[Fuse] None
[Output mode] All points independent
[Insulation method] Photoelectric isolation
[External circuit connection method] 20-point screw terminal block (M 3.5 screws)
[Input and output occupied points] 16 points
[DC5V internal consumption current] 130mA
[A1SY22 overall dimensions (H*W*D)]:130*34.5*93.6mm
[A1SY22 weight] 0.25KG
A1SY28A Mitsubishi Ans series output module, A1SY28A price (face price) 2180
A1SY28A Mitsubishi Ans series output module parameter description: 8 points AC100V~240V 1A/1 point, bidirectional thyristor output, all points independent terminals, 8A/1 common terminal, response time 1ms+0.5 cycle, 20-point terminal block
