Brand: MITSUBISHI/Japan Mitsubishi
Origin: Category Imported
AY70 Mitsubishi A series 16-point transistor output module is a 16-point transistor output module of Mitsubishi A series PLC! AY70 price (face price) 2840, AY70 function description, AY70 parameter description.
AY70 parameter description: 16-point DC5/12 transistor sink output for TTL and CMOS 16mA/1 point, 128A/1 common terminal, response time 1ms, 8 points 1 common terminal, sink output, 20-point terminal block
AY70 Mitsubishi A series 16-point transistor output module performance specifications:
[Output points] 16 points
[Rated load voltage] DC5V/12
[Voltage usage range] DC4.5~15V
[Maximum load current] 16A/1 point 128A/1 common terminal
[Maximum inrush current] 50A 10ms or less
[Leakage current when OFF] VOH: DC3.5V (VCC=DC5V, IOH=0.4mA)
[Maximum voltage when ON] V0L: DC0.2V (IOL=16mA)
[Response time] OFF->ON 1ms or less, ON->OFF 1ms or less
[Surge suppressor] None
[Fuse] None
[Protection function] None
[External power supply]
Voltage: DC5/12V (DC4.5~15V)
Current: 55mA (TYP. DC24V, each common terminal)
[Common terminal arrangement] 8 o'clock 1 common terminal
[Insulation method] Photocoupler isolation
[External connection] 20 points-terminal block (M3 screw)
[Number of occupied input and output points] 16 points (I/O allocation: output 16 points)
[Internal current consumption (DC5V)] 120mA
[AY70 overall size H*W*D] 250*37.5*100mm
[AY70 weight] 0.36KG
