AY71 Mitsubishi A Series PLC

AY71 Mitsubishi A series PLC is a 32-point transistor output module of Mitsubishi A series PLC! AY71 price (face price) 3730, AY71 function description, AY71 parameter description. AY71 parameter description: 32-point DC5/12 transistor sink output for TTL and CMOS 16mA/1 point, 256A/1 common terminal, response time 1ms, 16 points 1 common terminal, sink output, 38-point terminal block

Product Description

Brand: MITSUBISHI/Japan Mitsubishi

Origin: Category Imported

AY71 Mitsubishi A series PLC performance specifications:

[Output points] 32 points

[Rated load voltage] DC5V/12

[Voltage usage range] DC4.5~15V

[Maximum load current] 16A/1 point 256A/1 common terminal

[Maximum inrush current] 50A 10ms or less

[Leakage current when OFF] VOH: DC3.5V (VCC=DC5V, IOH=0.4mA)

[Maximum voltage when ON] V0L: DC0.2V (IOL=16mA)

[Response time] OFF->ON 1ms or less, ON->OFF 1ms or less

[Surge suppressor] None

[Fuse] None

[Protection function] None

[External power supply]

Voltage: DC5/12V (DC4.5~15V)

Current: 55mA (TYP. DC24V, each common terminal)

[Common end arrangement] 16 points 1 common end

[Insulation method] Photocoupler isolation

[External connection] 38 points-terminal block (M3 screw)

[Number of occupied input and output points] 32 points (I/O allocation: output 32 points)

[Internal current consumption (DC5V)] 200mA

[AY71 overall size H*W*D] 250*37.5*131mm

[AY71 weight] 0.44KG

AY71 Mitsubishi A series PLC is a 32-point transistor output module of Mitsubishi A series PLC! AY71 price (face price) 3730, AY71 function description, AY71 parameter description.

AY71 parameter description: 32-point DC5/12 transistor sink output for TTL and CMOS 16mA/1 point, 256A/1 common terminal, response time 1ms, 16 points 1 common terminal, sink output, 38-point terminal block
