AY72 Mitsubishi A Series PLC

Brand: MITSUBISHI/Japan Mitsubishi

Origin: Category Imported



AY72 Mitsubishi A series PLC performance specifications:

[Output points] 64 points

[Rated load voltage] DC5V/12

[Voltage usage range] DC4.5~15V

[Maximum load current] 16A/1 point 512A/1 common terminal

[Maximum inrush current] 50A 10ms or less

[Leakage current when OFF] VOH: DC3.5V (VCC=DC5V, IOH=0.4mA)

[Maximum voltage when ON] V0L: DC0.2V (IOL=16mA)

[Response time] OFF->ON 1ms or less, ON->OFF 1ms or less

[Surge suppressor] None

[Fuse] None

[Protection function] None

[External power supply]

Voltage: DC5/12V (DC4.5~15V)

Current: 55mA (TYP. DC24V, each common terminal)

[Common end arrangement] 32 points 1 common end

[Insulation method] Photocoupler isolation

[External connection] 40-pin connector*2 rows

[Number of occupied input and output points] 64 points (I/O allocation: output 64 points)

[Internal current consumption (DC5V)] 300mA

[AY72 overall size H*W*D] 250*37.5*106mm

[AY72 weight] 0.47KG



AY72 Mitsubishi A series PLC 64-point transistor output module! AY72 price (face price) 5500, AY72 function description, AY72 parameter description.



AY72 parameter description: 64 points DC5/12 transistor source output for TTL and CMOS 16mA/1 point, 512A/1 common terminal, response time 1ms, 32 points 1 common terminal, source output, 40-pin connector * 2 rows
