Mitsubishi PLC FX0N-3A analog special function module

Introduction of Mitsubishi PLC FX0N-3A analog special function module:
1. Mitsubishi FX0N-3A is an analog special function module: it has 2 input channels and one output channel.

Product Description

Introduction to Mitsubishi PLC FX0N-3A analog special function module :
1. Mitsubishi FX0N-3A is an analog special function module: it has 2 input channels and one output channel.
1) The input channel receives the analog signal and converts the analog signal into a numerical value;
2) The output channel adopts digital values and outputs the same amount of analog signals;
3) The maximum resolution is 8 bits. Mitsubishi PLC FX0N-3A analog special function module
2. The voltage and current selected on the basis of input / output are determined by the user's wiring method.
3. FX0N-3A can be connected to FX2N , FX2NC , FX1N , and FXON series programmable controllers.
4. All data transmission and parameter settings are through the TO/FROM instructions applied to the PLC .
FXON-3A ’s software control and adjustment, Communication between the PLC and FXON-3A is protected by an optocoupler.
5. FX0N-3A occupies 8 I/O points on the PLC expansion bus , and the 8 I/O points can be assigned to input or output.

External dimensions:
