Mitsubishi MCStoragia Inverter Connection License MCR-109A-INV(N)

The Mitsubishi MCStoragia Inverter Connection License MCR-109A-INV(N) is a specialized license designed to support automated backup and restoration of parameters for Mitsubishi Electric inverter products, including the FREQROL series. Integrated with the MCStoragia Standard system, the MCR-109A-INV(N) enables centralized management of inverter configuration data, allowing users to maintain operational continuity and reduce recovery time in case of system failures.

Product Description

Mitsubishi MCStoragia Inverter Connection License MCR-109A-INV(N)

Overview

The MCR-109A-INV(N) is an Inverter Connection License for Mitsubishi Electric’s MCStoragia Standard FA device backup software. Designed for industrial environments utilizing Mitsubishi FREQROL inverters, this license enables automated backup and restoration of critical inverter parameters, programs, and configuration data. It ensures operational continuity in motor-driven systems, minimizing downtime in applications such as manufacturing, HVAC, and material handling.

Mitsubishi MCStoragia.png

Key Features

Device Compatibility
- Supported Inverters:
  - FREQROL Series: A800, F800 (serial numbers with <Year/Month> ≥ 6/3).
  - FREQROL-E800 (serial numbers with <Year/Month> ≥ 21/1).
- Connection Methods:
  - Ethernet (direct or via CC-Link IE Field/TSN with iQ-R routing).
Backup & Restoration
- Backup Targets:
  - Programs, parameters, device comments, function block source information.
- Backup Formats: USB memory backup (A800/F800) or direct Ethernet backup (E800).
- Restoration Options:
  - Directly write backups to inverters via FR Configurator2.
  - Save backups to USB for offline recovery.
Security & Compliance
- Supports password authentication for secure inverters.
- Generates difference reports (PDF) to track parameter changes for audit compliance.
Scalable Licensing
- License Tiers:
  - 50 devices
  - 175 devices
  - 350 devices
- Flexibility: Scale licenses to match the size of your inverter network.

System Requirements

Component	Specification
Base License	Requires MCR-109A-BASE to activate MCStoragia Standard.
Operating System	Windows 10/11 Professional 64-bit (Japanese/English/Korean/Chinese) or Windows Server 2019.
Hardware	CPU: Intel® Core™ i7 or higher recommended; RAM ≥8GB; HDD ≥500GB.
Software	FR Configurator2 (for parameter configuration), SQL Server 2019/2022.
Network	- CC-Link IE Field: Requires iQ-R firmware ≥ 04 and network unit (RJ71EN71) firmware ≥ 11.

Configuration Guidelines

Standalone Mode: Ideal for small systems (≤50 inverters).
Distributed Mode: Deploy multiple Agent PCs for large-scale networks (up to 350 devices).
Network Setup:
- For CC-Link IE Field routing, ensure proper network parameter configuration.
- Limit network layers to ≤3 to avoid connection timeouts.

Applications

Motor Control Systems: Safeguard parameters for pumps, fans, conveyors, and compressors.
Energy Efficiency: Restore optimized inverter settings to maintain energy-saving profiles.
Compliance: Maintain audit trails for ISO 50001 (energy management) or industry-specific standards.

Purchasing & Support

Order Codes:
- MCR-109A-INV(50): 50-device license.
- MCR-109A-INV(175): 175-device license.
- MCR-109A-INV(350): 350-device license.
Technical Support:
- Email: [email protected]

Important Notes

Firmware Requirements: Verify inverter serial numbers and firmware versions before integration.
Licensing: Licenses are server-bound and cannot be shared across multiple servers.
Performance: Backup speed depends on network stability and project complexity.
