Mitsubishi MCStoragia CNC Connection License MCR-109A-C70(N)

Mitsubishi MCStoragia CNC Connection License MCR-109A-C70(N)

Overview

The MCR-109A-C70(N) is a specialized CNC Connection License for Mitsubishi Electric’s MCStoragia Standard FA device backup software. Designed for manufacturing environments utilizing Mitsubishi CNC systems, this license enables automated backup and restoration of critical machining data, ensuring operational continuity and compliance with industrial standards. It integrates seamlessly with Mitsubishi’s CNC devices to safeguard programs, parameters, and configuration settings, minimizing downtime in precision-driven industries like automotive, aerospace, and machinery.

Key Features

1. Device Compatibility



   • Supported CNC Models:



     • Q Series CNC: Q173NCCPU.



2. Comprehensive Backup & Restoration



   • Backup Targets:



     • Machining programs, NC parameters, common variables, tool compensation data, work offsets, and NC sequence programs.



   • Backup Format: Remote Maintenance Tool-compatible files.

   • Restoration Options:



     • Directly write backups to CNC devices via Mitsubishi’s Remote Maintenance Tool.

     • Save backups locally for offline recovery.



3. Security & Compliance



   • Ensures data integrity during backup/restoration processes.

   • Maintains audit trails to track changes and comply with ISO or industry-specific regulations.



4. Scalable Licensing



   • License Tiers:



     • 20 devices

     • 50 devices

     • 100 devices



   • Flexibility: Scale licenses based on the number of CNC devices in your system.

System Requirements

Configuration Guidelines

• Standalone Mode: Ideal for small systems (≤20 CNC devices).

• Distributed Mode: Deploy multiple Agent PCs for large-scale systems (up to 100 devices per Agent).

• Network Requirements:



  • Connection: Ethernet (hub connection) for direct communication with CNC devices.

  • Firmware: Ensure CNC devices run Mitsubishi’s latest firmware for compatibility.

  • Routing: Set routing parameters if connecting through 3+ network layers.

Applications

• High-Precision Machining: Protect NC programs for CNC lathes, mills, and multi-axis machines.

• Rapid Recovery: Restore machining parameters during equipment failures to minimize production delays.

• Regulatory Compliance: Maintain version control and audit logs for certifications (e.g., ISO 9001).

Purchasing & Support

• Order Codes:



  • MCR-109A-C70(20): 20-device license.

  • MCR-109A-C70(50): 50-device license.

  • MCR-109A-C70(100): 100-device license.



• Technical Support:



  • Email: [email protected]

Note:

• Licenses are server-specific and cannot be shared across multiple servers.

• Ensure CNC devices are accessible via Ethernet for optimal performance.

• Backup speed may vary depending on network latency and program complexity.

Safety & Compliance:

• Always use the latest firmware and follow Mitsubishi’s guidelines for secure operations.

• Refer to the official documentation for updates and compatibility details.
