Mitsubishi MCStoragia Motion Connection License MCR-109A-QDSCPU(N)

The Mitsubishi MCStoragia Motion Connection License MCR-109A-QDSCPU(N) is a connection license for motion CPU devices, enabling automated backup and secure restoration of programs and parameters for Mitsubishi Electric models like Q172DCPU, Q173DCPU, and R64MTCPU. Designed for integration with MCStoragia Standard systems, the MCR-109A-QDSCPU(N) enhances reliability, minimizes downtime, and supports efficient maintenance workflows across industrial automation environments.

Product Description

Mitsubishi MCStoragia Motion Connection License MCR-109A-QDSCPU(N)

Overview

The MCR-109A-QDSCPU(N) is a Motion CPU Connection License for Mitsubishi Electric’s MCStoragia Standard FA device backup software. This license enables automated backup and restoration of programs, parameters, and critical data for Q Series Motion CPUs, ensuring seamless integration with Mitsubishi’s advanced motion control systems. Designed for manufacturing environments with complex motion control requirements, this license supports compliance, fault recovery, and efficient maintenance workflows.

Mitsubishi MCStoragia.png

Key Features

Device Compatibility
- Supported Motion CPUs:
  - Q Series: Q172DCPU(-S1), Q173DCPU(-S1), Q172CPU(N), Q173CPU(N).
  - R Series: R16MTCPU, R32MTCPU, R64MTCPU (limited to specific firmware versions).
Backup & Restoration
- Full Backup: Captures motion control programs, parameters, and configuration data.
- Comparison Backup: Detects changes in motion programs/parameters and backs up only modified data.
- Direct Restoration: Restore backups via MELSOFT MT Works2 or save locally for offline recovery.
Security & Compliance
- Supports password authentication for secure motion control CPUs.
- Maintains audit trails for version control and regulatory compliance.
Scalable Licensing
- License Tiers:
  - 20 devices
  - 50 devices
  - 100 devices
- Flexibility: Scale licenses based on the number of Motion CPUs in use.

System Requirements

Component	Specification
Base License	Requires MCR-109A-BASE (¥1,000,000) for MCStoragia Standard activation.
Operating System	Windows 10/11 Professional 64-bit (JP/EN/KR/CN) or Windows Server 2019.
Hardware	CPU: Intel® Core™ i7 or higher recommended; RAM ≥8GB; HDD ≥500GB.
Software	MELSOFT MT Works2 (for Motion CPU programming), SQL Server 2019/2022.

Configuration Guidelines

Standalone Mode: Suitable for small systems with ≤20 Motion CPUs.
Distributed Mode: Deploy multiple Agent PCs to manage large-scale motion control systems (up to 100 devices per Agent).
Network Requirements:
- Firmware: Q Series Motion CPUs require firmware version SV13/SV22 or later.
- Routing: Set routing parameters when connecting through 3+ network layers.

Applications

Robotics & Automation: Backup motion programs for robotic arms, conveyors, and CNC machines.
High-Precision Manufacturing: Ensure quick recovery of motion control parameters in semiconductor or automotive production.
Audit Compliance: Track changes in motion logic for ISO or industry-specific standards.

Purchasing & Support

Order Codes:
- MCR-109A-QDSCPU(20): 20-device license.
- MCR-109A-QDSCPU(50): 50-device license.
- MCR-109A-QDSCPU(100): 100-device license.
Technical Support:
- Email: [email protected]
