Mitsubishi MCStoragia CPU Connection License MCR-109A-CPU(N)

The Mitsubishi MCStoragia CPU Connection License MCR-109A-CPU(N) is a specialized connection license engineered for seamless, automated backup and restoration of CPU-based FA devices in industrial environments. Designed for reliability and scalability, the Mitsubishi MCStoragia CPU Connection License MCR-109A-CPU(N) ensures that critical program data and configuration settings are securely preserved, reducing downtime and enhancing operational continuity.

Send Inquiry

Product Description

Mitsubishi MCStoragia CPU Connection License MCR-109A-CPU(N)

Overview

The MCR-109A-CPU(N) is a CPU Connection License for Mitsubishi Electric’s MCStoragia Standard FA device backup software. This license enables automated backup and restoration of programs, parameters, and critical data for MELSEC PLC CPUs across multiple series. It is essential for users managing medium-to-large-scale manufacturing systems requiring secure and efficient device backup solutions.

Mitsubishi MCStoragia.png

Key Features

Device Compatibility
- Supported PLC Series:
  - MELSEC iQ-R Series (e.g., R00CPU, R16ENCPU, R120SFCPU).
  - MELSEC iQ-F Series (FX5U, FX5UC).
  - MELSEC Q/F/L/A Series (e.g., Q03UDV, FX3U, L26CPU-PBT, A2USH-S1).
Backup & Restoration
- Full Backup: Captures programs, parameters, labels, comments, and device memory.
- Comparison Backup: Detects changes in programs/parameters and backs up only modified data.
- Direct Restoration: Restore backups via GX Works3/GX Developer or save locally for offline recovery.
Security Integration
- Supports file passwords and user authentication for secure CPUs.
- Ensures compliance with industrial safety standards.
Scalable Licensing
- License Tiers:
  - 20 devices
  - 50 devices
  - 100 devices
- Flexibility: Purchase licenses based on the number of CPUs requiring backup.

System Requirements

Component	Specification
Base License	Requires MCR-109A-BASE for MCStoragia Standard activation.
Operating System	Windows 10/11 Professional 64-bit (JP/EN/KR/CN) or Windows Server 2019.
Hardware	CPU: Intel® Core™ i7 or higher recommended; RAM ≥8GB; HDD ≥500GB.
Software	SQL Server 2019/2022, GX Works3/GX Works2 (customer-provided).

Configuration Guidelines

Standalone Mode: Ideal for small systems (≤100 devices).
Distributed Mode: Combine multiple Agent PCs to handle large-scale systems (up to 5,000 devices).
Cloud Integration: Monitor backups remotely via cloud databases.

Applications

Manufacturing: Minimize downtime by restoring PLC programs during malfunctions.
Audit Compliance: Maintain version history and audit trails for regulatory requirements.
Multi-Device Management: Centralize backups for diverse MELSEC PLCs across production lines.

Purchasing & Support

Order Codes:
- MCR-109A-CPU(20): 20-device license.
- MCR-109A-CPU(50): 50-device license.
- MCR-109A-CPU(100): 100-device license.
Technical Support: Contact Mitsubishi Electric Software Corporation:
- Email: [email protected]

Note:

Licenses are non-transferable between servers.
Performance may vary based on network configuration and project size.
Refer to the latest official documentation for firmware compatibility and updates.
